Growing and Photographing Crystals

by Becky Killian

"Pink Quartz" Crystal Cluster


Equipment Used

Nikon D70

60mm macro lens

Tripod and copy stand

Sheet of glass 12x12

Tungsten light source

Black light source




Crystals
Crystals are solid substances in which the smallest units are arranged in repeating geometrical patterns. Crystals have attracted people to them because of their beauty and some believe in their magical or medicinal powers. Although normally it takes extreme heat and pressure and perhaps thousands of years for crystals to grow in their natural state, you can grow crystals in your own home in a short amount of time. The two crystals I grew were alum and sugar crystals.


Alum

Alum crystal

Growing crystals at home was suprisingly easy to accomplish. To grow Alum crystals I had to purchase "Alum" at the grocery store in the spice isle. I then mixed the powder with warm water and let it sit overnight. In the morning you can see a substantial amount of crystals growing in the bottom of the cup. By using a bigger "seed" crystal and the rest of the alum mixture, you can let your crystal grow until it is the size you want. This photograph was taken of a 2 week old alum crystal and was shot using transilluminated polarized light. Polarized lighting was accomplished by placing the crystal between two matched polarized filters and rotating the filters to obtain the image most desired.

Sugar Crystals

Sugar crystals or rock candy is also an easy crystal to grow at home. By mixing sugar and water and by using similar procedures as the alum crystal, you can grow beautiful sugar crystals in a matter of weeks. This crystal was grown in 2 weeks and the photograph was taken with a transilluminated tungsten light source to emphasize the square or rock shaped crystals. (Recipes to grow your own crystals can be found in the resources section below.)

Sugar


Lighting Techniques
The two main lighting techniques I used to photograph these crystals were 45 degree side light illumination and transillumination.



45 degree side light illumination

I obtained this lighting by setting up a mini-studio with a backdrop to highlight the subject's qualities. Since this subject is multifaceted and has texture, I used 45 degree side lighting to capture the shadows and highlights of the crystal. This is obtained by placing the light source at a 45 degree angle from the subject.

"Golden Citrine" Crystal Cluster (Tungsten)

Geode Crystals (Tungsten)



"Rama Quartz" Crystal (Black Light)


Transillumination

Transillumination literally means to cause light to pass through. Crystals are translucent and I think are best lit by using transillumination. The setup I used for this lighting technique was obtained by using a sheet of glass elevated so the light source can be placed underneath the glass. The crystal was then placed on top of the glass and the camera was attached to a tripod with the lens pointing straight down to the subject.

Transillumination setup

Alum Seed Crystals (Tungsten)

"Rama Quartz" Crystal (Tungsten)


Resources
Crystal growing recipes: http://rockhoundingar.com/pebblepups/growcryst.html

All other crystals were grown from the Smithsonian Crystal Growing kit. You can purchase this kit online at Wal-mart: http://www.walmart.com/catalog/product.gsp?product_id=1574679

I am currently a 3rd year student at Rochester Institute of Technology studying Biomedical Photography. This website was designed for a Photomacrography class taught by Ted Kinsman. If you have any questions or comments regarding this webpage, please contact me at bxk4335@rit.edu. Thanks for looking!

All images copyright by Becky Killian 2004
